Cygnus 2+ Hands Free

O novo Cygnus 2PLUS é um medidor de espessura multimodo simples de usar, com capacidades de eco múltiplo, eco-eco e eco único, ideal para trabalhos com escalada e acesso com corda devido seu visor rotativo na extremidade.
Ideal para uso em placas planas, superfícies curvas ou tubos, com tecnologia de sonda de cristal único de múltiplos ecos, o que significa poder medir através de revestimentos espessos e visualizar apenas a espessura do metal.

O Cygnus 2PLUS ainda conta com o recurso Multiple-Echo, que oferece medições simples e precisas, com o benefício adicional de Echo-Echo e Single-Echo, usando sondas de cristal gêmeas para corrosão extrema, Echo-Echo para medições em metais pintados, mas com corrosões, corrosões na parede traseira pesada e, Eco Único para medições em superfícies não revestidas com face frontal pesada e ou corrosões de parede traseira e materiais atenuantes, como metais fundidos ou plásticos.

Características técnicas do Cygnus 2+ Hands Free

Características do do Cygnus 2+ Hands Free

Multiple-Echo for reliable, accurate through coating measurements
Single-Echo and Echo-Echo measuring modes
OLED multi-functional display with improved readability in all lighting conditions
Extremely rugged enclosure – shock and impact to MIL STD 810G
Environment sealing to IP67 – MIL STD 810G
Deep-coat mode – measures through coatings up to 3/4″ (20 mm) thick
Cygnus echo-strength bars assist thickness measurements in Multiple-Echo mode
TPE over molded enclosure
Buttons designed for minimum of 100,000 depressions
Fully sealed battery compartment (contains any leaking battery fluids)
MSI™ (Measurement Stability Indicator) – for Single-Echo and Echo-Echo modes
Single-Echo and/or Echo-Echo measuring modes with twin crystal probes
Automatic probe recognition for S2C and twin crystal probes.

Opcionais

Multi-Measuring Mode

Multiple-Echo uses three back wall echoes and measures remaining metal thickness while ignoring coatings. All measurements are error checked using 3 return echoes to give repeatable, reliable results. Accepted by all major classification societies. Uses single crystal probes for linear accuracy (and no probe zero required).

Echo-Echo uses two back wall echoes and measures remaining metal thickness while ignoring coatings up to 0.04″ (1 mm) thick using twin crystal probes for improved detection of back wall corrosion and pitting.

Single-Echo uses one back wall echo, measures remaining metal thickness on uncoated surfaces and is possibly helpful for areas with extreme front face or back wall corrosion and pitting. Effective on highly attenuative materials such as cast metals, plastics and composites.

MSI™ (Measurement Stability Indicator)

This clever technique helps ensure only stable measurements are displayed in Echo-Echo and Single-Echo modes. Displayed measurements change color from red to green and vibrate alert to indicate a stable reading.


Cygnus Probes and Cables

Stainless Steel INOX Single Crystal Probes

The INOX probes have an updated ergonomic design and an easier to read frequency, identification and serial numbering. All frequencies of INOX probes have a black face and a color coding system to identify probe frequency.

Used in Multiple-Echo mode, these probes require no zeroing, have a high linear accuracy, are ideal for general thickness gaging and on pipes and have replaceable wear membrane for long life.

Stainless Steel INOX Twin Crystal Probes

Used in Echo-Echo and Single-Echo modes and focused ultrasound beam with improved measurability on extreme back wall corrosion and pitting.


Cygnus Cables

Using standard industry connectors the probe lead uses a custom made over molded cable that offers superior flexibility and resistance to oils and ultraviolet light. The cable will not stiffen after exposure to ultraviolet light.

Flexible Handling

Along with the wrist and neck straps supplied in the kit there is also an optional belt clip, offering a range of flexible handling solutions for all types of applications.
